BAVARIAN DEMON CORTEX PRO

Reference: BD96022

Condition: New product

Cortex Pro opens up the next generation gate with even more demoniac features and fun factors.

Bavarian Demon CORTEXpro: 3 axis fixed wing gyro system

Based on the latest 32-bit CPU technology and in addition to all state-of-the-art features, the brand new CORTEXpro offers a bunch of great news for more comfort in flight and setup.

More details

Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

More info

With the introduction of the CORTEXpro, bavarianDEMON opens up the next generation's gate of 3-axis stabilization systems for fixed-wing aircraft.

Based on the latest 32-bit CPU technology and in addition to all state-of-the-art features, the CORTEXpro offers a bunch of great new options for more flexibility, compatibility, comfort in flight and setup.

The combination of easy programming and basic setup without software, automatic signal type detection, compatibility with all common analog and digital serial protocols, as well as the dual and redundant serial input and output option, are absolutely unique.

Let the DEMON take control over your cockpit and test the CORTEXpro now! More fun, more safety, more comfort – presumably, only your breath will backpedal...

Featuring:

Multi protocoll input and output
Latest 32-bit technology
Up to 24 channels, 16 stabilized
Receiver redundancy for 2 inputs
Jeti integration and telemetry
Easy teach-in via radio
No software needed for basic setup
iOS & Android App via Bluetooth module (under development)

The Cortex Pro's firmware can be updated online quickly and simple via the internet. For hints and instructions, please see the software.

Specifications:

Dimensions: 40x30x14mm
Supply voltage: 4 to 10V (2S LiPo compliant, mini 5,5 V for Spektrum sats)
Current drain: 70 mA
Temperature range: -15°C to 55°C
Max turn rate: 500°/s on all axis
Switching servo framerate (via software): Digital 166/200/333 Hz - Analog 55 Hz
Maximum combined servo current: max continuous 15 A - Max short term 18 A
Weight: 27 g (without cable)
Supported receivers: Cable loom (PWM single channel), PPM sum (Jeti PPM sum pos. + Graupner SUM-0), Jeti EX-Bus, Futaba S-Bus 1, Graupner HOTT SUM-D (SRXL), Multiplex M-Link (SRXL), JR X-Bus (Mode A + B/SRXL).
Supported pulse width range (output): 950-2050 ms.

In the box:

CORTEXpro sensor unit
One mounting foam tape each: Soft ACP and Acro ACP
150mm connection cable loom (optional 250 mm longer cable avalaible, see accessories)
Mini USB cable for computer connection
Quick-Start-Guide (brief installation and setup manual)
