650X Tail Pitch Assembly (H65T006XX)

● Designed for Align T-Rex 650X radio controlled helicopter.
● The metal tail pitch assembly features high precise bearing structure and high rigid CNC processes aluminum alloy material, and therefore this component is absolutely helpful for the accuracy of flying movement control and the flight stability of the new T-Rex 650X.

Specifications:

● Slider Shaft x1 (Φ8x7x17.6mm)
● Bearing holder x1 (13.5x12.5x9.5mm)
● Bearing mount washer x1 (Φ7xΦ8.3x3.5mm)
● Control link x2 (Φ12.75xΦ6x3.9mm)
● 700 Collar x2 (Φ2.5xΦ3.5x4mm)
● 600 Metal T type arm x1 (27x8x11.2mm)
● Bearing MR117ZZ x2 (Φ7xΦ11x3mm)
● Collar screw x2 (M2x8mm)
● Socket Button Head Collar Screw x2 (M2.5x8mm)
