RCE-BL80A Align Brushless ESC (HES08003)

Reference: HES08003

Condition: New product

New 32 bits M4 ARM processor.

Align RCE-BL80A: 80A Brushless ESC (3-6S input voltage) adjustable High Voltage 10A Built-in BEC

With rc helicopter Governor mode.

More details

Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

More info

Align RCE-BL80A: this brand new ESC controller for electric brushless motor is built with adjustable BEC voltage, allowing continuous current of 10A and more, also support surge current support up to 25A. Much power and precision for your radio controlled helicopter onboard electronics !
Moreover, it's built with high quality 32 bit M4 ARM processor offering superior governor performance, support the best flight performance for all pilots in every level.
Suitable for T-Rex 500X/500L/500PRO DFC and other Class 500 rc helicopters.

1. Superior 32 bits M4 ARM Processor.
2. High Quality MOSFET.
3. Adjustable Voltage and 10A powerfull BEC.
4. Excellent Governor Function.
5. Cool ESC Temperature Keep it Much Reliable.
6. Support ASBOX Multifunction Programmer Set Up.
Suitable for T-REX 500X/500L/500PRO DFC

Specifications:

● Contimuous current: 80A
● Surge current: 100A
● Supporting input voltage: 3S~6S LiPo / 11.1V~22.2V
● Supporting battery types: Li-Poly 3~6 cells
● BEC output: 5~8V, Continuous 10A / Surge 25A
● Size: 70x38.2x20.4mm
● Weight: Approx. 97g

In the box:

RCE-BL80A ESC
Heat shrink tube x2 (Red, Black)
Hook and loop tape x2
